Our Products
Pluto Air Cooler
Ductable Air Cooler
Top & Bottom Discharge
Coolsup to 2500 sq.ft. (with 75 feet line up Ducting) 1.5 Unit Consumption in 1 Hour 22000 CMΗ

Particulars | Pluto Air Cooler |
---|---|
Airflow (M3/H) | 22000 CMH |
Discharge | Top / Bottom |
Cooling Area (Sq. Ft.) | 2500 Sq. Ft. |
Air Pressure (P.A) | 240 |
Motor (V/Hz) | 380-415V / 50Hz & 220V / 50Hz |
Power (Kw) | 1.5 |
Phase | Three / Single |
Speed | Single |
Fan Type | Axial (4 Blade) |
RPM (Running Per Minutes) | 1400 |
Pad Size (MM) | 685 × 765 × 100 |
Water Tank (LTR.) | 35 |
Water Drain | Manual / Auto |
Noise (DB) | < 75 |
Net Weight (Kg) | Top - 68, Bottom - 62 |
Dust Filter | Yes |
Air Outlet Size (MM) | 670 × 670 |
Dimension L×W×H (MM) | 1111 × 1111 × 1011 |
Advantages of Pluto Air Cooler
Energy Efficient: Consumes significantly less electricity compared to traditional air conditioning systems.
Eco-Friendly Cooling: Uses water evaporation, producing zero carbon emissions and minimizing environmental impact.
Improved Air Quality: Filters out dust, allergens, and pollutants while providing fresh, cool air.
Lower Operating Costs: Reduces cooling expenses with its cost-effective and energy-saving design.
Simple Installation: Easy to set up with minimal installation requirements, saving time and labor costs.
Humidity Control: Adds moisture to dry air, creating a more comfortable indoor environment.
Durable Construction: Made with high-quality materials for long-lasting and reliable performance.
Low Maintenance: Requires minimal servicing due to its straightforward and robust design.
Customizable Options: Available in various sizes and models to meet specific cooling needs.
Versatile Applications: Ideal for residential, commercial, and industrial use in hot and dry climates.

Benefits
Energy-Efficient Operation
- Consumes up to 80% less energy than traditional HVAC systems.
- Lower operational cost, especially suitable for continuous use.
Environmentally Friendly
- Uses natural evaporation process without harmful refrigerants.
- Lowers carbon footprint and promotes green cooling.
Easy Installation & Maintenance
- No ducting or complex piping required.
- Minimal maintenance with accessible components (fan, motor, pump, pads).
Fresh & Filtered Air Supply
- Pulls in fresh air, filters it through wet cooling pads, and removes dust and pollutants.
- Reduces indoor air pollution and improves air quality.
Effective Cooling for Large Areas
- Designed for high air delivery (measured in CMH/CFM)
- Uniform airflow covers wide spaces more effectively than traditional coolers
Operates in Semi-Open or Open Areas
- Ideal for environments where traditional air conditioning is ineffective or uneconomical.
- Suitable for partially ventilated areas with constant heat load.
Dual Voltage & Phase Options Available
- Available in single-phase and three-phase models with dual voltage (220V/380-415V).
- Flexible installation across different industrial setups.
